Application
Description
- Ensuring that perfectly circular ink droplets are accurately and consistently placed during the?printing process helps achieve compactness, high speed, high quality, and high image quality.
- Support grayscale printing: The print head provides smooth gradients and finer?image quality by?freely controlling the volume of the ejected droplets.
External fans and heater
One external heater and dryer fans was integrated in one part.
Media touching switch
When carriage touch the media, switches could be on, and system emergency stop printing.
Media detector
When media is going to use up, system could pause printing.
Press rolls
Adopt rubber pressure roller to ensure more precise and smooth paper feeding without warping the paper.
Printhead height adjustment
You can adjust the height between head plate and media by manual.
Heating control board
Front / middle / back heating could be controlled by a smart board.
Specifications
| Product Model | Easyjet 1801 | Easyjet 1802 |
| Number of Printhead | 1 | 2 |
| Printhead Type | F1080/13200/11600/DX5/DX7 | |
| Printhead Height | 2-3mm | |
| Printhead Cleaning | Fully automatic deaning with anti-clogging, flash spraying, and autom atic moisturizing functions | |
| Ink Type | Eco-Solvent/Water-Based/Sublimation Inks | |
| Ink Color | 4 colors (C/M/Y/K); 6 colors (C/M/Y/K/Lc/Lm);8colors(C/M/Y/K/Lc/Lm/Lk/LLk) | |
| Ink Cartridge Capacity | 1500ml per color | |
| Ink Supply Method | Negative pressure continuous ink supply system | |
| Printing Width | 1830mm | |
| Media | Photo Paper / PP Paper/Canvas /Rice Paper / Vehicle Vinyl / Heat Transfer Paper, and More. | |
| Maximum Roll Weight | ＜40kg | |
| Take-up Device | Standard Configuration | |
| Heating System | Three-Stage Embedded Constant Temperature Heating System (Front, Middle,Back) | |
| Drying Configuration | Dual infrared heating with external drying fan | |
| Operation Language | Chine se/English | |
| Computer System | Win11/Win10/Win7 | |
| Working Environment | Temperature range 18*C-25*C; Humidity range 35%-65% Rh | |
| Printing Interface | Gigabit Bhernet Port | |
| RIP Software | Maintop/Photoprint | |
| Power Parameters | AC-220V,50Hz/60Hz | |
| Power (W) | min: 32W;max: 2300W | |
| Noise Level | Standby<32dB, operating s65dB | |
| Machine Dimensions | 2750*8300*1660mm(L*W*H) | |
| Machine Weight | 215 Kg | |
| Package Dimensions | 2750*760*660mm(L*W*H) | |
| Package Weight | 240Kg | |
